DH1.0
Recirculation of water in Bathtub pump
Recirculation of water in SPA equipment
Working conditions
Medium temperature: 5-50℃
Environmental temperature: ≤50
Max.working pressure: 0.3MPa
Insulation F
IPX5 Waterproof Standard
Thermal Protector: TI.USA
230V/60Hz,110V/60Hz,110V/50Hz models are available on request
| Model | Qmax (l/min) | Hmax (m) | V/Hz | Power（P1) | Amps | Fitting Size (mm) | |
|---|---|---|---|---|---|---|---|
| KW | HP | ||||||
| DH1.0 | 340 | 10.5 | 220-240/50 | 0.75 | 1 | 3.8 | 48.5 or 50 |
| PS: 230V/60Hz,110V/60Hz,110V/50Hz models are available on request | |||||||
Product Details Gallery
