WTC50M
Mariculture circulation filter
Recirculation of water in Bathtub pump
Recirculation of water in SPA equipment
Working conditions
Medium temperature: 5-50℃
Environmental temperature: ≤ 50℃
Max.working pressure: 0.3MPa.
Insulation F
IPX5 Waterproof Standard
Thermal Protector: TI.USA
| Model | V/Hz | Speed (r/min) | Power（P1) | Amps | Qmax (l/min) | Hmax (m) | Curves | Fitting Size (mm) | |
|---|---|---|---|---|---|---|---|---|---|
| KW | HP | ||||||||
| WTC50M | 220-240/50 | 1400 | 0.25 | 0.35 | 1 | 240 | 3.8 | 1 | 48.5 or 50 |
| WTC50M | 220-240/60 | 1700 | 0.25 | 0.35 | 1 | 240 | 3.8 | 1 | 48.5 or 50 |
| WTC50M | 220-240/50 | 1400 | 0.18 | 0.25 | 0.8 | 180 | 2.8 | 2 | 48.5 or 50 |
| 220-240/60 | 1700 | 0.25 | 0.35 | 1 | 240 | 3.8 | 1 | 48.5 or 50 | |
| PS: 110V/60Hz,110V/50Hz models are available on request | |||||||||
